Greenlee is proud to introduce the 701K-G6A, a fully upgraded version of their powerful Greenlee 701K industry standard professional Tone and Probe cable pair tracing kit. The 701K-G6A Tone and Probe kit offers superior tracing for low voltage applications such as telephone, data, and security alarm wiring. New - LED headlight for improved viewing in dark rooms, cabinets & man holes. New - Headset jack allows headphones to be used in noisy environments. New - Provides an audible and visual continuity tester for short circuit testing. New - External warble - select alternating 890/960 Hz New - Improved - DC input voltage protection. New - Large angled bed-of-nail alligator clips Included in the 701K-G6A kit is the 77HP-G6A (Alligator Clips) high power Tone Generator with short circuit checker, the 200EP-G Tone Tracing Probe, an RJ11/45 coupler, alternate flat/spade plastic and round metallic probe tips, and a durable nylon case. Features: Fast, accurate wire identification Sends tone to identify wires Two distinct tone signatures Polarity indication Continuity test Talk battery supply Adjustable volume control Visual signal strength indication Large...
AMPLIFIER PROBE (181 CB-A) - Made in Taiwan (we also have other model from USA) The Amplifier Probe is designed to identify and trace wires or cables within a group without damaging the insulation Works with any Tone Generator to identify wires Volume control for increased sensitivity and adjustable to suit work enviornment Recessed ON/OFF button prevents battery drain Power supply is from any 9V battery with a life of approximately 100 hours A plug receptacle is designed for head set or hand set *better than proskit cable tracer.
FEATURES Multi-purpose Cable Tester ● 165 CB is an ideal tool which can test the correct pin configuration for different kinds of cables.● For testing: -RJ45/RJ11 -USB -COAX -BNC cable -Multi-wire cable● Auto-scan and manual-check function● Buzzer sound warning for wire status● 2 LED module indicators on the master unit which can do both of transmitter and receiver functions for RJ45/RJ11 cable testing. Users don't need to use the receiving unit.● 165 CB provides a variety for checking cable continuity, open status, short status and miss-wired. ● Ground (shielded ) wire test.● LED indication for wire status.● Power source : 9V batteryAmplifier Probe ● The Amplifier Probe is designed to identify and trance wires or cables within a group without damaging the insulation. ● The flashlight function for easier cable tracing in the dark.● An LED indication for the signal strength. ● Volume control for increased sensitivity and adjustable to suit work environment.● Recessed...
FEATURES Cable Tracer ● Trace wires or cables.● Volume control.● Tip & Ring identification.● 2 bi-colored LEDs ( Line 1 & Line 2).● Tone speed selection : Fast & Slow.● A phone jack is designed for headset or handset. (Amplifier probe) Digital Multimeter ● 4000 counts.● ACV, DCV.● Ohm, Diode, & Continuity testing.● Auto-range.● Data hold.● Low battery indication.● Select function.● Auto-off. SPECIFICATIONS AC Voltage Range Resolution Accuracy 400mV 0.1mV ±(1.0%rdg+5dgt) 4V 1mV 40V 10mV 400V 100mV 750V 1V DC Voltage Range Resolution Accuracy 400mV 0.1mV ±(0.5%rdg+3dgt) 4V 1mV 40V 10mV 400V 100mV 1000V 1V Resistance Range Resolution Accuracy ...
