FLI0003- i5 Compact Infrared Thermal Imaging Camera WITH 'TRUE' WARRANTY

Compact Infrared Thermal Imaging Camera
100 x 100 resolution, 21° × 21° Field of View



  • Easy-to-use troubleshooting tool, pocket sized and fully automatic
  • Spot measurement mode
  • Temperature range: -4 to 482°F (-20 to 250°C)
  • Thermal Sensitivity (N.E.T.D): <0.1°C @ 25°C
  • High accuracy of ±2% helps you find problems faster and easier
  • Large 2.8" color LCD, focus-free lens
  • MiniSD card stores up to 5000 Radiometric JPEG format images
  • Includes QuickReport software for analysis of radiometric images

The FLIR i5 thermal imaging infrared camera offers 100 x 100 pixels of infrared resolution with 2% accuracy and < 0.1°C at 25°C thermal sensitivity - a robust combination of capabilities to quickly detect electrical, mechanical, HVAC and energy-audit-related problems. One-handed operation is unsurpassed for quick and easy menu access and feature selection. It comes complete in a hard carrying transport case.
This new, next generation FLIR i-Series of compact thermal cameras feature: Higher resolutions for more detailed images and measurements. Wider fields of view for quicker scans of larger areas. And a more rugged design for tough environments.

Thermal Imagers and Infrared Camera Industry Applications

Asphalt

Automation/OEM

Automotive

Building Diagnostics

Energy Audits

Food

Home Inspection

Law Enforcement

Manufacturing

Marine Surveyor

Medical

PetroChem

Predictive Maintenance

Pulp and Paper

R&D/Testing

Range Phenomenology

Roofing

Steel

Utility Market

Veterinarian



Specifications for Flir i5

Thermal sensitivity (N.E.T.D)

<0.1°C at 25°C

Field of view/min focus distance

21° x 21°/0.6m (2 ft.)

IR Image Resolution

100 x 100 pixels

Measurement modes

Spot

Temperature range

-4°F to 482°F (-20°C to 250°C)

Image Storage

5000 Images (microSD card memory)

Emissivity

Emissivity Table; 0.1 to 1.0 adjustable

Frame Rate

9Hz

Focus

Focus Free

Spectral Range

7.5 to 13μm

Display

Built-in 2.8" color LCD

Image Modes

Thermal - Palettes (Iron, Rainbow, and Black/White)

Set-up Controls

Date/time, °C/°F, 21 languages

Battery Typer/Operating Time

Li-lon/ >5 hours, Display shows battery status

Charging System

In camera, AC adapter; 3 hours to 90% capacity

Shock

25G, IEC 68-2-29

Vibration

2G, IEC 68-2-6

Dimensions

8.8 x 3.1 x 3.4" (223 x 79 x 85mm)/<12.9oz. (365g), including battery




Model

Description

I5

Flir i5 Compact Infrared Thermal Imaging Camera, 100 x 100 resolution.


  • 1 - 2 GB MicroSD Card
  • 1 - MiniSD adaptor
  • 1 - Li-Ion rechargeable battery
  • 1 - 100-240V AC adaptor /charger with US, EU, UK, & AU plugs
  • 1 - USB Mini-B cable
  • 1 - Built-in manual lens shutter
  • 1 - Hand strap
  • 1 - Hard case
